- Cooling mode:
- air cooling
- Device subtype:
- backup power system
- Dimensions ( LxWxH ):
- 442 x 410 x 150 m
- Frequency:
- 50 Hz
- Harmonic distortion:
- <3%
- Humidity range:
- 5% to 95%
- Input voltage range:
- 90~280 VAC
- Max. charging current:
- 100 A
- Max. discharge current:
- 100 A
- Max. input power:
- 5500 W
- Max. output current:
- 30 A
- Max. peak power:
- 10000 VA
- MPPT voltage range:
- 120~450 V
- Noise level:
- 60 dB
- Operating temperature:
- charging: 0 ~45 °C
- Overload current:
- 40 A
- Power factor:
- 1
- Protection level:
- IP20
- Rated battery voltage:
- 51.2 V
- Rated output power:
- 5000 W
- Automatic switching time:
- <10 ms
- Battery operating voltage range:
- 44, 8 ~ 57, 6 V
- Depth of discharge ( DoD ):
- 95 %
- EMC certification level:
- EN61000
- Estimated battery service life:
- 6, 000 cycles
- Max. AC input current:
- 60 A
- Max. charging power from AC mains:
- 3150 W
- Max. input current from PV panel:
- 100 A
- Operating temperature range:
- 15 °C ~ 55 °C
- PV panel charging type:
- MPPT
- PV panel operating voltage range:
- 120~500 V
- Rated operating altitude:
- <2000 m
- Rated output voltage ( VAC ):
- 220
- Standard charging current:
- 50 A
- Standard discharge current:
- 50 A
- Storage temperature range:
- -25 °C ~ 60 °C
- Max. number of batteries connected in parallel:
- 15
